Description |
|
| |
1. Compact and portable, applicable for PC and Notebook
2. Standard USB interface and Windows based fingerprint application
¡¡software.
3. Use chip based sensor for live-scan capturing of 3D-fingerprint
Minutiae.
4. Fingerprint identification with high accuracy and speed.
5. Use software protections including Logon, Screen Saver, and File
¡¡encryption & decryption (Standard version).
6. Hard Disk, File, Folder and Application locks (Professional
version).
¡@ |
|
| |
|
|
| |
Features |
|
| |
1. Software automatically ignores residual fingerprints.
2. Use chip-based sensor can efficiently detect fingerprint with
scar, cut,
¡¡swelling and dry or wet fingers.
3. High speed of digital conversion and classification.
4. Easy operation of fingerprint enrollment.
5. Use encryption technology of high security.
6. Identification by Fingerprint minutiae does not save any
fingerprint image.
7. Applicable for ID confirmation in IT, civil, law enforcement,
financial,
¡¡E-commerce industries as well as e-transaction, etc.
¡@ |
|
| |
|
|
| |
Specification |
|
| |
|
Sensor |
Semiconductor |
|
Hardware Interface |
USB |
|
Resolution |
500DPI |
|
Field Size |
300X300 pixels |
|
Gray Level |
256 levels (8 bits/pixel) |
|
Minutia Size |
512~1024 bytes |
|
False Rejection Rate (FRR) |
1/1,000 |
|
False Acceptance Rate (FAR) |
1/1,000,000 |
|
Allowable Rotation |
 15 |
|
ESD |
20kV (FMS-1A ) / 12kV (FMS-2A) |
|
Allowable Displacement |
10 mm |
|
Matching Speed |
< 1 second
|
|
Scanning Speed |
1/5 second |
|
Dimension |
3.5(H) ¡Á5(W) ¡Á11(L) (cm) (FMS-1A)
8.5(H) x5.5(W) x 1.5(L) (cm) (FMS-2A)
|
|
Weight |
300g (FMS-1A )/ 500g (FMS-2A) |
|
Power Consumption |
DC5V x 110mA |
|
Hardware requirement |
Pentium200 / above 32M RAM |
|
|
|
| |
| |
|
